Digital Multimeter
The Ronix RH-9602 is a professional True RMS Digital Multimeter featuring 4000 counts, NCV detection, and a wide temperature range.
45,000 د.ع
متوفّر
توصيل لكل المحافظات
الدفع عند الاستلام
ضمان رسمي
The Ronix RH-9602 is an advanced digital multimeter for technicians who demand precision across a range of electrical parameters. Equipped with True RMS technology and a 4000-count display, it delivers accurate readings for AC/DC voltage, current, resistance, and capacitance, even in complex non-linear circuits. Its ability to measure temperatures up to 1000°C and detect live voltage without contact (NCV) makes it suitable for both industrial maintenance and electronic repair.
| Model | RH-9602 |
|---|---|
| DC Voltage Range | 40mV/400mV/4V/40V/400V/ 1000V |
| AC Voltage Range | 40mV/400mV/4V/40V/400V/750V |
| Current DC Range | 400uA/4000uA/40mA/400mA/4A/10A |
| Current AC Range | 400uA/4000uA/40mA/400mA/4A/10A |
| Resistance Range | 400Ω/4k Ω/40k Ω/400k Ω/4M Ω/40MΩ |
| Capacitance Range | 6nF/60nF/600nF/6uF /60uF/600uF /6mF/60mF/100 mF |
| Frequency Range | 10hz/100hz/1000hz/10khz/100khz/1mhz/20mhz |
| Temperature Range | (-20～1000)℃ /(-4～1832)℉ |
| input impedance | 10 MΩ |
| Sampling rate | Approx. 3times/second |
| AC Frequency Response | 40Hz~1k Hz |
| Operation Mode | Auto /manual |
| Max. Exhibition | 3999 Counts |
| LCD Size | 68.2*47.9 mm |
| Body Material | ABS |
| Power supply | 1.5V AAA battery |
| operating temperature range | 0 ~ 40 ℃ |
| Weight (include four 1.5V batteries) | Approx 395 g |
| Safety Rating | 1000V CATIII 600V CATIV |
| Dimensions | 186×92×52 mm |
| Supplied In | Color box |
| Include | 4pcs AAA battery,1pc test leads,1pc temperature probe |
| Accuracy Rang of DC Voltage | 40mV/400mV(±(0.5%+5) 4V /40V /400V (±(0.5%+4)) 1000V ±(1.0%+6) |
| Accuracy Rang of AC Voltage | 40mV/400mv ±(1.0%+6) 4V/40V/400V(±(0.8%+10)) 750V±(1.2%+10) |
| Accuracy Rang of DC Current | 400uA/4000uA(±(1.0%+10)) 40mA/400mA(±(1.2%+8)) 4A/10A(±(1.2%+10)) |
| Accuracy Rang of AC Current | 400uA/4000uA/40mA/400mA (±(1.5%+10)) 4A/10A (±(2.0%+5)) |
| Accuracy Rang of Resistance | 400Ω(±(0.8%+5) 4k Ω/40k Ω/400k Ω/4M Ω±(0.8%+4) 40MΩ(±(1.2%+10)) |
| Accuracy Rang of Capacitance | 6nF (±(5.0%+40) 60nF/600nF/6uF /60uF/600uF 士(3.5%+20) 6mF 士(5.0%+10) 60mF/100 mF ±10% |
| Accuracy Rang of Frequency | 10hz/100hz/1000hz/10khz/100khz/1mhz/20mhz ±(0.5%+10) |
| Accuracy Rang of Temperature | (-20-1000)℃ <400℃ ±(1.0%+5) ≥400℃ ±(1.5%+15) (-4~1832)℉ <752℉ ±(1.0%+5) ≥752℉ ±(1.5%+15) |
| Low battery indication | yes |
| backlight | yes |
| Data hold | yes |
| True RMS | yes |
| Auto Power Off | yes |
| shockproof protection | yes |
| Duty Cycle | yes |
